MF 240 PERFORMANCE: |
| Engine HP @ 2250 RPM |
50 (BS)* |
| Max. Torque @ 1350 RPM |
173.5 Nm (128 Lbf. ft.) |
| P.T.O HP @ rated Engine Speed |
44 hp* |
| P.T.O HP @ 540 RPM |
39 hp* |
| * Manufacturer's Estimate |
|
MF 240 ENGINE: |
| Make/Model |
AD 3.152 |
| Type |
Diesel |
| No. of Cylinders |
3 |
| Injection |
Direct Injection |
| Bore |
91.44 mm (3.6 in) |
| Stroke |
127.0 mm (5.0 in) |
| Capacity |
2.5 Litre (152.7 Cu. Ins.) |
| Compression Ratio |
16.5:1 |
| Starting Aid |
Thermostat |
| Cooling |
Water |
| Air Cleaner |
Oil Bath |
| Air pre-cleaner |
Over-bonnet |
MF 240 ELECTRICS: |
| Voltage |
12 V, Negative Earth |
| Battery |
96 Amp. Hour |
| Alternator |
32 Amp |
| Starter |
45 Amp |
MF 240 CLUTCH: |
| Type |
Dual |
| Diameter |
254 x 305 mm (10 x 12 in) |
MF 240 POWER TAKE - OFF: |
| Type |
Live PTO |
| Speed |
540 RPM @ 1789 |
| Engine RPM |
|
| Shaft Diameter |
35 mm (1.375 in) |
| No. of Splines |
6 |
MF 240 TRANSMISSION: |
| No. of Gears 8 Forward, 2 Reverse |
|
| Min/Max Road Speeds at Rated Engine Speed with 11 - 28 Wheels is 1.62/30.00 km per hour |
MF 240 HYDRAULICS: |
| Functions |
Draft Control |
| Piston Control |
|
| Response Control |
|
| Constant Pumping |
|
| Max. Output |
(3.52 lmp.gal/min) |
| Max. Lift Force |
16 litres/min. |
| At Lower link ends, |
1415 Kg (3120 lbs.) |
| 3 - Point Linkage |
Category 1 & 2 Interchangeable Balls |
MF 240 BRAKES: |
| Type |
Oil Board Drum Brakes Independent or locked together |
| Dimensions |
355 mm x 50 mm (14 in x 2 in) |
MF 240 TYRES: |
| Front |
6.00 - 16 (6PR) Pressed Wheels (4.5 x 16 Rim) |
| Rear |
12.4/11 - 28 (6PR) Pressed Wheels |
MF 240 TRACK ADJUSTMENT: |
| In Increments of 101.6 mm (4 in.) |
1.22 m - 1.93 m |
| Front |
(48 in.) - (76 in.) |
| Rear |
1.32 m - 1.9 m |
| |
(52 in.) - (75 in.) |
MF 240 DIMENTIONS: |
| (With 6.00 - 16 Front and 11 - 28 Rear Wheels and 52 ins. Track Setting) |
| Overall Length |
3.21m (126 in) Links Horizontal |
| Overall Width |
1626 mm (64 in) |
| Overall Height |
|
| - To Top of Exhaust |
2165 mm (85.25 in) |
| - To Steering Wheel |
1400 mm (55.12 in) |
| Wheel Base |
1.89 m (74.5 in) |
| Turning Circle |
|
| - Using Brakes |
5.56 m (219 in.) |
| - With out Brakes |
6.20 m (244 in.) |
| Ground Clearance under |
|
| - Clutch Housing |
338 mm (13.31 in.) |
| - Front Axle |
531 mm (20.9 in.) |
| - Rear Axle |
555 mm (21.85 in.)
|
MF 240 WEIGHTS: |
| (With 6.00 - 16 Front and 11 - 28 Rear Tyres in Running Condition) |
| Front Axle |
695 Kgs (1532 lbs.) |
| Rear Axle |
945 Kgs (2083 lbs.) |
| Total |
1640 Kgs (3615 lbs.) |
MF 240 CAPACITIES: |
Fuel Tank
|
52 litres
|
| Engine Sump |
6.8 litres |
| Hydraulics |
32 litres |
| Steering Box |
0.9 litres |
| Engine Cooling |
10.2 litres |
MF 240 STANDARD FITTINGS: |
Comprehensive Instrumentation: Flat Fenders with Handle and Protected Lights:
More Comfortable Spring Suspension Seat, Plough Lamp, Visible Number Plate, Warning Lights, Vertical Exhaust, Hand and Foot Accelerator, Differential Lock, Safety Start Switch, Adjustable Top Link, Rear PTO Shield, Horn, Tools Box, Standard Toolkit, Over Bonnet Pre-cleaner, Indicator Lights, Stabilizer Chains, Front end Weight Frame. |
MF 240 OPTIONAL EQUIPMENT: |
| Range of Farm Implements, PTO Pulley, 9-Hole Draw Bar, Stays, Fiber Glass Top Sun Canopy with Frame, Ground PTO, Frond End Weights, Rear View Mirror, Hydraulic Spool Valves, Swinging Draw Bar. |
|
|
| |
